192 Powermax125 Service Manual 808070
9 – Power Supply Component Replacement
Figure 62
2
3
4
6
7
8
9
5
1
1 CSA power cord
2 CE power cord
3 Ferrite core
4 Rear panel
5 Strain relief retention nut
6 Power switch
7 L3
8 L2
9 L1
