Hypertherm Powermax 125 Service Manual

Powermax125 Service Manual 808070 233
9 – Power Supply Component Replacement
Install the quick disconnect receptacle
1. Secure the quick disconnect receptacle to the front panel by tightening the 4 supplied mounting screws to 23 kg-cm
(20 inch-pounds). See Figure 91 on page 234.
2. From the front of the power supply, insert the small end of the silver-plated fitting into the center hole of the quick
disconnect receptacle until fully seated.
3. Install the plastic washer over the silver-plated fitting and the plastic hub on the rear of the quick disconnect
receptacle.
4. Place the ring terminal over the silver-plated fitting and tighten the brass nut onto the silver-plated fitting. Tighten the
nut to 46.1 kg-cm (40 inch-pounds), but do not overtighten – the plastic washer should be able to spin when the
brass nut is installed.
5. Push the 90° push-to-connect fitting onto the silver-plated fitting until fully seated.
6. Route the nozzle wires through the protective sheathing in the center panel.
7. Route the torch interface cable through the center grommet.

Hypertherm Powermax 125 Specifications

General

Output Current	30-125 A
Input Power	15.2 kW
Open Circuit Voltage	300 VDC
Gas Supply	Clean, dry, oil-free air or nitrogen
Input Power Cable Length	10 ft (3 m)
Rated Output Current	125 A
Gas Type	Air or nitrogen
Cutting Capacity	1-1/4 inch (32 mm)
Pierce Capacity	1 inch (25 mm)
Input Voltage	200-600 V, 3-PH
Duty Cycle	100% @ 125 A
Certifications	CSA
Maximum Clean Cut Thickness	1-1/4 inch (32 mm)
Cooling Method	Fan-cooled
Torch Options	Hand
