Powermax125 Service Manual 808070 247
9 – Power Supply Component Replacement
8. From the power board side, remove the 2 ferrite cores installed over the long transformer wires while removing the
transformer from the power supply.
Figure 102
Long transformer wires
Ferrite cores
