The status indicator lights operate under application-program control. Table 8
describes the typical use of these indicator lights. Refer to your store’s operating
procedures for specific actions to take when the status indicators are lit.
Table 8. Keyboard status-indicator lights meanings
Light Meaning
Wait A The application program running on the terminal is
waiting for an action to complete (for example, waiting for
a program to load).
Offline B Normal online operations have been interrupted and you
can display an offline message using system function
keys. An offline message gives you information related to
the offline condition.
Message Pending C A system message is waiting to be displayed on the
terminal, and can be displayed using system function
keys.
Unlabeled D Reserved
Using the USB keyboard-V
The keyboard-V contains various controls, switches, indicators, and features.
Keyboard status indicators
The status indicators show the operating status of the POS terminal.
A
B
C
D
Figure 115. Location of keyboard status-indicator lights
Figure 116. Location of keyboard-V status indicators
Updated October 31, 2007
110 SurePOS 700 Series: SurePOS 700-721/741/781, 722/742/782 Planning, Installation, and Operation Guide
