Step 4. Installing the slanted I/O tray (wide units only)
Depending upon your configuration, you will need to install the slanted I/O tray.
1. Install the two mounting clips (A in Figure 30) into the slanted I/O tray. From
the inside of the I/O tray, insert the back of the mounting clip first and push the
front part into the opening.
2. Turn the I/O tray over. Push on the front of the tab until it clicks into place.
3. Set the I/O tray on top of the unit, and connect the tabs in front of the unit.
4. Attach the I/O tray to the cash drawer by inserting and tightening the two plastic
thumbscrews into the holes at the back corners of the I/O tray.
A
Figure 30. Installing two mounting tabs into the slanted I/O tray
Updated October 31, 2007
38 SurePOS 700 Series: SurePOS 700-721/741/781, 722/742/782 Planning, Installation, and Operation Guide
