Chapter 6 Illustrated Parts Breakdown
403
(Figure 40)
Item
No.
Part No. Description Notes
1 39U2542 Shuttle Cover Assembly Air Shroud Assembly. Includes items
2 and 8.
2 Ref Screw, Captive (2) 10-24x.62 with O-ring, .125x.250x.06
3 Ref Screw, Thread Forming (4) 6-32x.25
4 Ref Barrier Shield
5 Ref Power Supply Shield Taped to card cage along upper edge
6 57G1468 Belt, Timing, 050P, 100 Teeth Paper Feed Belt
7 54P1379 Platen/Paper Feed Cover Kit Paper feed belt cover shown in Figure
40. Platen open belt cover: item 24,
page 413.
8 14H5179 Paper Scale
