Chapter 6 Illustrated Parts Breakdown
409
Figure 43. This illustrated parts breakdown shows the magnetic pickup unit (MPU) and extension spring.
<21> Make sure the extension
spring does not touch the MPU
cable after installation.
Spring Lug (Do not
remove grease)
Spring Lug (Do not
remove grease)
1
2
3
A
See detail for
flywheel clearance
0.010 ± .001 inch (0.254 ± .025 mm)
A
4
5
6
To Next Page
