408
9 14H5330 Shuttle Motor Cable Assembly
10 39U2533
02N6214
Hammer Bank Power Cable Assembly
Hammer Bank Power Cable Assembly
Use on all except 6500-v20
6500-v20 only
11 14H5288 Housing, Connector Kit (P106/P107) P107, Motor Sensor, Right
12 14H5287 Centronics I/O Cable Assembly See also page 284.
13 14H5300 operator panel Cable Assembly See also page 293.
14 14H5211 Clamp, Shaft, Receiving
15 Ref Screw, Captive, Power Supply (3)
16 75P2810
10R4054
SIMM, Flash Memory, 8 MB
SIMM, Flash Memory, 16 MB
Must install in slot J11. J10 is not
used. See also page 341.
17 Ref DIMM, SDRAM, 32MB, 144 Pin Soldered to controller board
18 Ref Security Key (Comes with emulation) See also page 341
19 Ref Paper Feed Motor
20 Ref RibbonMinder Bar Code Sensor Assembly
21 54P1456 Cable Assembly, PS I/O, 2000 Used only on model 6500-v20. (See
also page 289.)
22 Ref Not Used
Item
No.
Part No. Description Notes
