Chapter 6 Illustrated Parts Breakdown
407
(Figure 42)
Item
No.
Part No. Description Notes
1 39U2494
39U2495
39U2496
39U2508
Ribbon Mask/Hammer Bank Cover Assy, 500
Ribbon Mask/Hammer Bank Cover Assy, 1000
Ribbon Mask/Hammer Bank Cover Assy, 1500
Ribbon Mask/Hammer Bank Cover Assy, 2000
Model v05 and v5P
Model v10 and v1P
Model v15
Model v20
2 39U2498
39U2497
39U2500
39U2499
39U2502
39U2501
39U2506
39U2503
54P1527
54P1528
54P1529
75P2817
Shuttle Assembly, 05
Shuttle Assembly, 05, Advance Exchange
Shuttle Assembly, 10
Shuttle Assembly, 10, Advance Exchange
Shuttle Assembly, 15
Shuttle Assembly, 15, Advance Exchange
Shuttle Assembly, 20
Shuttle Assembly, 20, Advance Exchange
Hammer Spring Assembly, 05
Hammer Spring Assembly, 10
Hammer Spring Assembly, 15
Hammer Spring Assembly, 20S
Model v05 and v5P
Model v05 and v5P
Model v10 and v1P
Model v10 and v1P
Model v15
Model v15
Model v20
Model v20
Model v05 and v5P
Model v10 and v1P
Model v15
Model v20
3 39U2548
39U2528
39U2547
39U2527
39U2549
39U2529
Power Supply, PFC, 5/10
Power Supply, PFC, 5/10, Advance Exchange
Power Supply, PFC, 15
Power Supply, PFC, 15, Advance Exchange
Power Supply, PFC, 20
Power Supply, PFC, 20, Advance Exchange
Model v05, v5P, v10, and v1P
Model v05, v5P, v10, and v1P
Model v15
Model v15
Model v20 (shown in Figure 42)
Model v20 (shown in Figure 42)
4 Ref P101 Cable Connector Part of item 3
5 Ref Cable Assy, AC-In, Power Supply Part of Field Kit AC Assy 14H5289
6 39U2546
39U2556
Controller PCBA, (V5)
Controller PCBA, (V5) Adv Exch
7 14H5288 Housing, Connector Kit (P106/P107) P106, Motor Sensor, Left
8 14H5279 Hammer Bank Logic Cable Assembly See also page 295.
