412
(Figure 44)
Item
No.
Part No. Description Notes
1 Ref Screw, Socket Cap, 6-32x.312 Trilob (Self-
Tapping) (2)
2 Ref Plate, Tractor Shaft, Left
3 54P1474 Bearing, Ball, Sealed
4 39U2537 Paper Support (2)
5 54P1475 Tolerance Ring,.37X.25,.006 THK,SS
6 39U2510 Splined Shaft Assembly (Blue Handle)
7 Ref Screw, Socket Cap, 6-32x.312 Trilob (Self-
Tapping)
8 Ref Plate, Tractor Shaft, Right
9 57P1181 Support Shaft
10a
10b
39U2543
39U2544
Tractor Set, With Steel Rollers, 20 (Blue)
Tractor Set, Non-Rollers, 05/10/15 (Blue)
Model v20 with or without power
stacker. Includes L&R tractors.
All others without Power Stacker.
Includes L&R tractors.
11 Ref Right Side Plate
12 Ref Left Side Plate
