IBM Infoprint 6500-v05 - Page 414

414
(Figure 45)
Item
No.
Part No. Description Notes
1 Ref Setscrew Part of item 25
2 Ref Bracket, Platen (2) Part of item 25
3 57G1469 Ironer Assembly, Reverse Paper Feed
4 Ref Screw, Thread Forming (3) 6-32x.25
5 54P1476 Ironer Bracket/Plate Field Kit
6 Ref Plate, Ironer Part of item 5
7 10R4285 Platen Assembly
8 Ref Washer, Flat (2) Part of item 25
9 Ref Screw (2) Part of item 11
10 Ref Washer, Flat #4 (2) Part of item 11
11 39U2509 Platen Switch Kit Platen Interlock Switch
12 Ref Screw, Socket Cap, 6-32x.75 Part of item 15
13 Ref Washer Part of item 15
14 Ref Nut Part of item 15
15 39U2538 Platen Stop Lever Kit
16 Ref Spring, Extension 1.12L Part of item 25
17 Ref Link, Spring Part of item 25
18 Ref Bearing, Nylon .376 Part of item 25
19 Ref Bracket, Switch Mount Part of item 11
20 Ref Wear Saddle, Platen (2) Part of item 25
