Chapter 6 Illustrated Parts Breakdown
415
21 57G1514 Platen Pulley, Driven
22 Ref Screw, Socket Cap, 6-32x.44 Part of item 21
23 57G1467 Belt, Timing, 312W, 87 Teeth Platen Open Belt
24 54P1379 Platen/Paper Feed Cover Kit Platen open belt cover shown in
Figure 45. Paper feed belt cover: page
400, item 7.
25 10R3798 Platen Hardware Kit
26 Ref Platen Washer Part of item 25
27 75P8169 Paper Ironer, Auxiliary Models v15 and v20 only: install this
part in front of item 3; that is, on the
shuttle side. All other models do not
use this item.
28 39U2555 Sensor Assembly, RibbonMinder/Barcode
29 Ref Screw
Item
No.
Part No. Description Notes
