IBM Infoprint 6500-v05 User Manual

468
7. Remove four cables from the stacker operator panel, and remove the stacker operator panel. (Figure 65.)
Figure 65. This figure shows how to remove the cables from the rear of the stacker operator panel.
A
Remove the
Tie Wrap
Logic Cable (P104)
Power Cable
Elevator I/O Cable
(P102)
Rail Cable (P107)
A
Ejection Lever
