List of Illustrations
499
(Figure 93)
Item
No.
Part No. Description Notes
36 24H9004 Stacker Hardware Kit Kit not illustrated
38b 54P1478 Switch Assy, Rocker, V3
40 24H8978 Anti-Static Brush
45 Ref Shear Grommet Part of item 36
46 Ref Cap Nut Part of item 36
47 10R4840
24H8988
53P8334
Drive Shaft Assy (Roller Drive Shaft)
Drive Roller
Grease (Shell Darina Grease 1)
Includes items 14, 70, 75, and 80
For Drive Shaft
49 Ref Bearing, Flanged Part of item 36
50 Ref Bearing Part of item 36
51 24H9003 Collar Clamp
52 Ref Collar, Setscrew Part of item 36
53 24H8997 Support Shaft
54 01P4689 Fence, Wireform
55 24H8981 Extension Spring
60 24H8982 Idler Roller
65 24H8983 Paddle, Power Stacker
70 24H9005 Driver Shaft (also spared as a lone item) Also sold separately
75 24H9006 Spacer (also spared as a lone item) Also sold separately
80 39U2513 Compression Spring (also spared as a lone item) Also sold separately
To Next Page
