IBM V7000 User Manual

444 IBM Flex System V7000 Storage Node Introduction and Implementation Guide
Select Global Mirror and a new window appears with two additional fields for the optional
Cycling Mode of Global Mirror, as shown in Figure 9-122. Then click OK to change the type of
relationship from MM to GM.
Figure 9-122 Optional Cycling mode setting
Finally restart your relationship. Click Start from the Actions drop-down menu as shown in
Figure 9-123.
Figure 9-123 Start of Remote Copy Relationship
Important: At the end of this procedure, when you start the relationship, be aware that the
data on the secondary volume is not usable until the synchronization process is complete.
We strongly suggest to take a Flashcopy before starting the relationship to maintain a
consistent copy at the secondary site.

IBM V7000 Specifications

General

Model	IBM Storwize V7000
Storage Type	Hybrid Flash Array
Maximum Capacity	1.2PB
RAID Levels	0, 1, 5, 6, 10
Connectivity	8 Gbps Fibre Channel, 16 Gbps Fibre Channel, 1 Gbps iSCSI, 10 Gbps iSCSI
Management	Command-line interface (CLI), Graphical user interface (GUI)
Form Factor	2U
Drive Bays	12
Maximum Raw Capacity	1.2PB
Operating System Support	AIX, HP-UX, Linux, VMware, Windows
Data Reduction Features	Real-time Compression, Deduplication
Drive Types	SSD, HDD
Scalability	Scale-up (drive enclosures) and scale-out (clustering) capabilities
