Chapter 11. SAN connections and configuration 505
Notice that the zone is associated with the required zoneset as specified when the zone was
created and named in Figure 11-47 on page 504.
Activating the zoneset
The aliases and zones have been created and placed in the zoneset; all that is required now
is to activate the zoneset. To do so, highlight the zone that you want to activate with the
mouse and click Apply in the bottom right side corner of the window as shown in
Figure 11-49. When you are prompted to save the zoning, click Save Zoning. To continue if
you are satisfied with the configuration changes you have made, click Yes.
Figure 11-49 Activate zoneset - order of tasks

IBM V7000 Specifications

General

Model	IBM Storwize V7000
Storage Type	Hybrid Flash Array
Maximum Capacity	1.2PB
RAID Levels	0, 1, 5, 6, 10
Connectivity	8 Gbps Fibre Channel, 16 Gbps Fibre Channel, 1 Gbps iSCSI, 10 Gbps iSCSI
Management	Command-line interface (CLI), Graphical user interface (GUI)
Form Factor	2U
Drive Bays	12
Maximum Raw Capacity	1.2PB
Operating System Support	AIX, HP-UX, Linux, VMware, Windows
Data Reduction Features	Real-time Compression, Deduplication
Drive Types	SSD, HDD
Scalability	Scale-up (drive enclosures) and scale-out (clustering) capabilities
