Chapter 12. Host configuration 537
Example 12-5 Output from SDDDSM - a disk with four paths is displayed
C:\Program Files\IBM\SDDDSM>datapath query device
Total Devices : 1
DEV#: 0 DEVICE NAME: Disk1 Part0 TYPE: 2145 POLICY: OPTIMIZED
SERIAL: 60050760008F0006F800000000000039
============================================================================
Path# Adapter/Hard Disk State Mode Select Errors
0 Scsi Port3 Bus0/Disk1 Part0 OPEN NORMAL 0 0
1 Scsi Port3 Bus0/Disk1 Part0 OPEN NORMAL 129 0
2 Scsi Port4 Bus0/Disk1 Part0 OPEN NORMAL 133 0
3 Scsi Port4 Bus0/Disk1 Part0 OPEN NORMAL 0 0
C:\Program Files\IBM\SDDDSM>
In the previous output, note that the UID of the mapped IBM Flex System V7000 Storage
Node volume reflects the SERIAL number in the output from datapath query device.
8. Open the Windows Disk Management window by clicking Start  Run, typing
diskmgmt.msc or simply open it from the Server Manager. You might have to click More
Actions  Rescan Disks before the FCoE attached disk displays.
Figure 12-37 shows the Windows Disk Management window with the uninitialized IBM
Flex System V7000 Storage Node disk.
Figure 12-37 Disk Management - FCoE attached disk displays
The next steps for getting access to the Windows disk are to initialize. This process is similar
to the WIN 2012 initialize function as described in 12.3.1, “Windows 2012 R2 Fibre Channel
volume attachment” on page 514.

IBM V7000 Specifications

General

Model	IBM Storwize V7000
Storage Type	Hybrid Flash Array
Maximum Capacity	1.2PB
RAID Levels	0, 1, 5, 6, 10
Connectivity	8 Gbps Fibre Channel, 16 Gbps Fibre Channel, 1 Gbps iSCSI, 10 Gbps iSCSI
Management	Command-line interface (CLI), Graphical user interface (GUI)
Form Factor	2U
Drive Bays	12
Maximum Raw Capacity	1.2PB
Operating System Support	AIX, HP-UX, Linux, VMware, Windows
Data Reduction Features	Real-time Compression, Deduplication
Drive Types	SSD, HDD
Scalability	Scale-up (drive enclosures) and scale-out (clustering) capabilities
