546 IBM Flex System V7000 Storage Node Introduction and Implementation Guide
3. Highlight the iSCSI Software Initiator and click Properties. The iSCSI initiator properties
window opens. Select the Dynamic Discovery tab (Figure 12-51) and click Add.
Figure 12-51 iSCSI Initiator properties
4. To add a target, enter the target IP address (Figure 12-52). The target IP address is the IP
address of a node in the I/O group from which you are mapping the iSCSI volume. Leave
the IP port number at the default value of 3260, and click OK. The connection between the
initiator and target is established.
Figure 12-52 Enter a target IP address
Repeat this step for each IBM Flex System V7000 Storage Node iSCSI port you want to
use for iSCSI connections.
iSCSI IP addresses: The iSCSI IP addresses are different for the cluster and canister
IP addresses; they have been configured in 6.2.2, “Creating an iSCSI attached host” on
page 276.

IBM V7000 Specifications

General

Model	IBM Storwize V7000
Storage Type	Hybrid Flash Array
Maximum Capacity	1.2PB
RAID Levels	0, 1, 5, 6, 10
Connectivity	8 Gbps Fibre Channel, 16 Gbps Fibre Channel, 1 Gbps iSCSI, 10 Gbps iSCSI
Management	Command-line interface (CLI), Graphical user interface (GUI)
Form Factor	2U
Drive Bays	12
Maximum Raw Capacity	1.2PB
Operating System Support	AIX, HP-UX, Linux, VMware, Windows
Data Reduction Features	Real-time Compression, Deduplication
Drive Types	SSD, HDD
Scalability	Scale-up (drive enclosures) and scale-out (clustering) capabilities
