568 IBM Flex System V7000 Storage Node Introduction and Implementation Guide
3. Restart the multipath daemon; see Example 12-30.
Example 12-30 Stopping and starting the multipath daemon
[root@palau ~]# service multipathd stop
Stopping multipathd daemon: [ OK ]
[root@palau ~]# service multipathd start
Starting multipathd daemon: [ OK ]
4. Type the multipath -dl command to see the mpio configuration. You see two groups with
two paths each. All paths must have the state [active][ready], and one group will show
[enabled].
5. Use the fdisk command to create a partition on the IBM Flex System V7000 Storage
Node disk, as shown in Example 12-31.
Example 12-31 fdisk
[root@palau scsi]# fdisk -l
Disk /dev/hda: 80.0 GB, 80032038912 bytes
255 heads, 63 sectors/track, 9730 cylinders
Units = cylinders of 16065 * 512 = 8225280 bytes
Device Boot Start End Blocks Id System
/dev/hda1 * 1 13 104391 83 Linux
/dev/hda2 14 9730 78051802+ 8e Linux LVM
Disk /dev/sda: 4244 MB, 4244635648 bytes
131 heads, 62 sectors/track, 1020 cylinders
Units = cylinders of 8122 * 512 = 4158464 bytes
Disk /dev/sda doesn't contain a valid partition table
Disk /dev/sdb: 4244 MB, 4244635648 bytes
131 heads, 62 sectors/track, 1020 cylinders
Units = cylinders of 8122 * 512 = 4158464 bytes
Disk /dev/sdb doesn't contain a valid partition table
Disk /dev/sdc: 4244 MB, 4244635648 bytes
131 heads, 62 sectors/track, 1020 cylinders
Units = cylinders of 8122 * 512 = 4158464 bytes
Disk /dev/sdc doesn't contain a valid partition table
Disk /dev/sdd: 4244 MB, 4244635648 bytes
131 heads, 62 sectors/track, 1020 cylinders
Units = cylinders of 8122 * 512 = 4158464 bytes
Disk /dev/sdd doesn't contain a valid partition table
Note: You can download example multipath.conf files from the IBM Subsystem
Device Driver for Linux website:
http://ibm.com/support/docview.wss?uid=ssg1S4000107#DM
