3 Preventive Maintenance Settings Dialog Box
17-6 WindO/I-NV4 Users Manual
This section describes the items and buttons on the Preventive Maintenance Settings dialog box and the
Individual Settings dialog box.
3.1 Preventive Maintenance Settings Dialog Box
The Preventive Maintenance Settings dialog box is used to manage the preventive maintenance settings for each
monitored device address.
Number of Items
Specifies the number of device addresses (1 to 256) to monitor. The numbers for the amount of configured devices is
displayed in Settings.
Display Options
Select the item to display in Settings from the following:
Settings
Edits the settings for each number.
3 Preventive Maintenance Settings Dialog Box
HG3G
HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T
HG4G HG1G HG1P
Operation Time: Operation time settings are displayed in Settings.
Operation Count: Operation count settings are displayed in Settings.
Operation Time + Operation Count: Operation time and operation count settings are displayed in Settings.
No.: Shows the number of the preventive maintenance settings to manage. Double
clicking the cell displays the Individual Settings dialog box. For details, refer
to “3.2 Individual Settings Dialog Box” on page 17-8.
Monitor Device Address: Shows the bit device or the bit number of the word device to count the operation time
or operation count.
Double clicking the cell displays the Tag Editor. For the device address configuration
procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-68.
Operation Time Device Address: Shows the destination device address for the counted operation time. You can
only specify an HMI Keep Register (LKR).
Double clicking the cell displays the Tag Editor. For the device address configuration
procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-68.
This option is only displayed when Operation Time or Operation Time +
Operation Count is selected in Display Options.
Data Type: Shows the date type of the Operation Time Device Address. Double clicking the cell
displays the Individual Settings dialog box. For details, refer to “3.2 Individual
Settings Dialog Box” on page 17-8.
This option is only displayed when Operation Time or Operation Time +
Operation Count is selected in Display Options.
