3 FTP Client Function
28-26 WindO/I-NV4 User’s Manual
Source
Select the source external memory device or the FTP server where the files to be copied or moved are stored from the
following items.
SD Memory Card
*1
, USB Flash Drive, (FTP server)
The No.+.(period)+Server Name of the FTP server specified in the FTP Server Manager is displayed.
Example: No. is 1 and Server Name is TestServer1
1.TestServer1
*1 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F only
Location: Selects the method to specify the save location of source files to copy or move.
Fixed: Specify the save location of the target folder or file path as a string. The maximum number is
247 characters.
Example: Copy or move files to the “ALARMLOG” folder under “HGDATA01” folder on the
external memory device
HGDATA01\ALARMLOG
Click on the External Memory Device Folder button or click on to the right on it, and then
select the item on the list.
Specify the Location by Value of Device Address:
Specifies a word device to specify a folder or file path of the files to copy or move. The path is
set by reading the values sequentially from the starting device specified and handling those
values as character data up to the character before NULL (0x00). The maximum number of
device addresses is 124 (2 characters per word device, maximum of 247 singlebyte characters).
Click to display the Tag Editor. For the device address configuration procedure, refer to
Chapter 2 “5.1 Device Address Settings” on page 2-68.
Files cannot be copied or moved from the FTP server to the FTP server.
When transferring files from external memory to external memory and HMI special internal relay LSM67 is
0, subfolders can be copied and moved up to five folders deep. When HMI special internal relay LSM67 is
changed from 0 to 1, subfolders cannot be copied or moved.
The following single-byte characters cannot be used in the folder or file path configured by Fixed or
Specify the Location by Value of Device Address.
; : * ? " < > |
Folder or File path that exceed the limits in Specify the Location by Value of Device Address and
folder or file path configured with characters that cannot be used are as follows.
- When the text of the folder or file path exceeds the maximum number of device addresses (no NULL),
the text stored in device addresses up to the maximum number of device addresses from the start is
configured.
- When a character that cannot be used is set, the text is up to that character.
If the transfer source is a MICRO/I configured as an FTP server, “A\” or “B\” must be specified at the
beginning of the path for each type of external memory.
Example 1: If the transfer source is the “ALARMLOG” folder in the “HGDATA01” folder on the SD
memory card:
A\HGDATA01\ALARMLOG
Example 2: If the transfer source is the “ALARMLOG” folder in the “HGDATA01” folder on the USB flash
drive:
B\HGDATA01\ALARMLOG
