WindO/I-NV4 User’s Manual 30-25
3 Analog I/O Modules
30
Expansion Modules
If the setting value is outside the range, a parameter setting error will occur.
■ Data type
If the setting value is 4 to 65,535, a parameter setting error will occur.
■ Minimum and maximum values
The minimum and maximum values can be set only when the data type is set to optional range. Set the minimum and
maximum values between -32,768 and 32,767. However, when signal type is set to PTC thermistor (threshold), set it
1, 2, or 4.
■ Filter
The setting value is rounded by 50.
When 50,001 to 65,535 is stored for the setting value, the filter operates as the maximum value of 50,000 ms.
■ Thermistor constant
17 Ni1000
18 NTC thermistor
19 PTC thermistor
20 PTC thermistor (threshold)
21 Resistance measurement
22 Expansion 0 to 20 mA
23 Expansion 4 to 20 mA
Setting Value Signal Type
Setting Value Data type
0 Binary data/Binary data (12 bits)
1 Optional range/Optional range (12 bits)
2 Celsius/resistance/Binary data (16 bits)
3 Fahrenheit/Optional range (16 bits)
Setting Value Filter
00 ms
50 50 ms
100 100 ms
150 150 ms
……
50,000 50,000 ms
Range Thermistor Constant
0 to 65,535 R0
-32,768 to 32,767 T0
-32,768 to 32,767 B
