2 Word Devices
33-12 WindO/I-NV4 User’s Manual
*3 HG5G/4G/3G/2G-V only
*6 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F only
*7 This is applicable for models with an audio interface only.
*8 This is applicable for models with a video interface only.
Device Address Function/Part
LSD249
*6
File transfer status to the SD memory card by using the FTP server function.
The following bit becomes to 1 while transferring files to SD memory card inserted into the MICRO/
I from an FTP client.
The bit becomes to 0 after transferring.
Bit 2: Recipe file
Bit 4: ZNV Project File
Bit 5: Picture file
Bit 8: Sound file
*7
Bit 9: ZLD Project File
Bit 10: Movie file
*8
Bit 15: None of the above
LSD250 to 255 Reserved
LSD256
*3
Input mode of Character Input
Stores the input method from the keypad for the Character Input.
0: Direct input mode
1: Kanji input mode
LSD257 to 259
*3
Reserved
LSD260
*3
BACnet communication status
Stores the status for BACnet communication.
Bit 0: Stopped
Bit 1: Ready
Bit 2: Operating
Bit 3: Stopped by error
LSD261
*3
BACnet Communication Error Information
Stores the last error information that has occurred in BACnet communication.
Bit 0: Normal
Bit 1: Invalid device ID
Bit 2: Invalid IP address
Bit 3: Invalid BBMD IP address
Bit 4: BBDM registration failure
LSD262 to 269
*3
Reserved
LSD270
*3
Expansion Module Slot 1 Information (Type ID and Status)
LSD271
*3
Expansion Module Slot 1 Information (System Software Version and Position Information)
LSD272
*3
Expansion Module Slot 2 Information (Type ID and Status)
LSD273
*3
Expansion Module Slot 2 Information (System Software Version and Position Information)
LSD274
*3
Expansion Module Slot 3 Information (Type ID and Status)
LSD275
*3
Expansion Module Slot 3 Information (System Software Version and Position Information)
LSD276
*3
Expansion Module Slot 4 Information (Type ID and Status)
LSD277
*3
Expansion Module Slot 4 Information (System Software Version and Position Information)
LSD278 to 383
*3
Reserved
