Page #1537 background imageLoading...
Page #1537 background image
WindO/I-NV4 User’s Manual 33-11
2 Word Devices
33
Internal Devices
*7 This is applicable for models with an audio interface only.
*8 This is applicable for models with a video interface only.
Device Address
Function/Part
LSD220
Ethernet port configuration error information
The following bits change to 1 when allocating the port numbers used by the various Ethernet
communications functions has failed.
The bits are 0 when allocating the port numbers was successful or a function is not used.
Bit 0: Maintenance Communication
Bit 1: Pass-Through
Bit 2: FC4A Series MicroSmart direct connection pass-through
Bit 3: User Communication
Bit 4: Web Server Function
Bit 5: FTP Server Function
Bit 6: FTP Client Function
Bit 7: E-mail Function
Bit 8: External Device Communication 1
Bit 9: External Device Communication 2
Bit 10: External Device Communication 3
Bit 11: External Device Communication 4
Bit 12: BACnet communication
LSD221 Number of e-mail in "Waiting" status
LSD222
Result of e-mail sending
0: Successfully Completed
1: Parameter error
2: Timeout error
3: Authentication error
4: None of the above
LSD223 E-mail Number which has been sent
LSD224 to 229 Reserved
LSD230 Number of the FTP server connected to using the FTP client function
LSD231
Number of file transfer successes
The register is set to 0 at the start of file transfers. 1 is added to the register when a file transfer
ends without any errors.
LSD232
Number of file transfer failures
The register is set to 0 at the start of file transfers. 1 is added to the register when any error occurs
in the file transfer.
LSD233 to 239 Reserved
LSD240, 241
Version number of the runtime system
Example: The version number of the runtime system is version 4.38.
LSD240=0438(Hex), LSD241=0000(Hex)
LSD242, 243
Version number of WindO/I-NV4
Example: The version number of WindO/I-NV4 is version 1.2.3.
LSD242=0102(Hex), LSD243=0300(Hex)
LSD244 to 247 Reserved
LSD248
File transfer status to the USB flash drive by using the FTP server function.
The following bit becomes to 1 while trasfering files to USB flash drive inserted into the MICRO/I
from an FTP client.
The bit becomes to 0 after transfering.
Bit 2: Recipe file
Bit 4: ZNV Project File
Bit 5: Picture file
Bit 8: Sound file
*7
Bit 9: ZLD Project File
Bit 10: Movie file
*8
Bit 15: None of the above
