■ Performance Specifications
■ EMC Specifications
*2 Please be aware that small black and bright dots might show up on LCD Screen: it is not a failure or malfunction.
*3 The time until brightness becomes 50% of the initial value.
The life of the LCD itself at an ambient temperature of 25°C. This is not a guaranteed value. The actual life depends on the
environment and conditions of use.
*4 The degree of protection for the operating section after the panel is attached. The compliance test has been passed, but this
is not a guarantee of operation in all environments. Not a guarantee in all usage environments with oil materials.
Type No. HG4G HG3G-A HG3G-8 HG2G-5F
Display
LCD Type
*2
TFT color LCD (TN Type)
Display Colors 65536 Colors
Effective Display Area (W × H)
246.0 × 184.5 mm 211.2 × 158.4 mm 170.4 × 127.8 mm 115.2 × 86.4 mm
Display Resolution (W × H) 800 × 600 dots 640 × 480 dots
View angle Left/Right: 80°, Top: 80°, Bottom: 60°
Left/Right/Top/
Bottom: 80°
Brightness of LCD only
550 cd/m
2
700 cd/m
2
600 cd/m
2
800 cd/m
2
Brightness Adjustment 48 levels
Backlight LED
Backlight Life
*3
Approx. 100,000 hours Approx. 50,000 hours
Touch
Panel
Switch Type Analog Resistive Film
Operating Force 3N maximum 0.55 to 2.3 N 3N maximum
Multiple Operations Impossible
Life 1,000,000 operations
User Memory Approx. 12 MB
Backup Battery
Coin type lithium manganese dioxide battery CR2032
Guarantee Period: 1 Year (Operating Temperature at 25°C)
Recommended Replacement Span: Every 5 Years (Operating Temperature at
25°C)
Backup Data Calendar, Log Data, HMI Keep Relays, HMI Keep Registers
Buzzer output Single tone (tone length is adjustable)
Degree of Protection
*4
IP66 (IEC60529)
TYPE 4X
TYPE 13
Weight (approx.) 2.1kg 1.65 kg 1.25 kg 0.65 kg
Radiated Emission
Class A : 10m
40dBµV/m quasi-peak (30M to 230MHz)
47dBµV/m quasi-peak (230M to 1GHz)
Electrostatic Discharge
Contact : ±6kV
Air : ±8kV
Electromagnetic Field
10V/m (80 to 1000 MHz)
3V/m (1.4 to 2.0 GHz)
1V/m (2.0 to 2.7 GHz)
80% AM (1kHz)
Fast Transient Burst
Power : ±2kV
Communication cable : ±1kV
Surge Immunity
±500V (between +24V and 0V)
±1kV (between +24V and FE, 0 and FE)
Conducted Radio
Frequency Immunity
3V (Power, Communication cable)
(150kHz to 80MHz)
80% AM (1kHz)
