IDEC MICRO/I HG1P-ST32 Series User Manual

2 HG4G/3G, HG2G-5F
35-30 WindO/I-NV4 User’s Manual
■ HG3G-A (10.4inch)
Unit: mm
# The size to the expansion module installation side
<Cable Attached Dimensions>
Depending on the type of connection cable used the dimensions shown above will change.
The dimensions given here are representative values and are intended for reference only.
30.9 #
44.4
52.7
46.7
199.5
212.0
11.4
36.5
6.0
270.0
257.5
10
257.5
199.5
55
50
30
