3 Project Settings Dialog Box
4-70 WindO/I-NV4 User’s Manual
Device Addresses for General Setting and Authentication Setting
When the Specify General setting and Authentication setting by Value of Device Address check box is
selected, it allocates the settings of the General Setting and the Authentication Setting starting at the device
address set in the Top Device Address. The details are shown below.
*1 When IP address is selected, use only four words from the beginning, and the remaining seventeen words are left as a
reserved area.
*2 The twenty-first word is recognized as a NULL terminating character (0x00) regardless of the value of device address.
*3 Add a NULL terminating character (0x00) as the end of the string data when the string length is less than twenty words.
Settings Address Number Words Data Format
Outgoing mail server (SMTP) +0 to +20
21
*1, *2
Host Name is selected: String
IP Address is selected: Decimal
Outgoing mail server (SMTP) port number +21 1 Decimal
Sender E-mail Address +22 to +42
21
*2, *3
String
Sender Name +43 to +63
21
*2, *3
String
Require authentication (LOGIN) to send E-mail
(0: Not require authentication,
1: Require authentication)
+64 1 Decimal
Account Name +64 to +85
21
*2, *3
String
Password +86 to +106
21
*2, *3
String
Use secure connection (SSL)
(0: Disable, 1: Enable)
+107 1 Decimal
String data is stored in the upper byte and lower byte according to the Storage Method of String Data
setting. For details, refer to “Storage Method of String Data” on page 4-28.
