6 Multi-Button
8-116 WindO/I-NV4 Users Manual
Source Data
Select the data handled by the operation selected for Action Mode.
Destination Device Address
*1 Advanced mode only
Value: Use a constant value.
Only a Value can be handled if Action Mode is set to Set or Set ON & OFF Data.
If Action Mode is set to Set ON & OFF Data, the value in the ON Data is written when the
button is ON, and the value in the OFF Data is written when the button is OFF.
Hexadecimal: Select this check box to enter the ON Data and OFF Data
values in hexadecimal.
Device Address: Use a value of device address.
Specify the device.
Click to display the Tag Editor. For the device address configuration
procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-68.
Use Reference Device Address
*1
:
Select this check box and specify a device address to change the
source word device according to the value of the specified device
address.
This setting is enabled only if Action Mode is set to Move.
For details, refer to Chapter 2 “Indirect Read and Indirect Write
Settings” on page 2-5.
Transfer
*1
:
Specify the number of word devices (1 to 64) to transfer.
This setting is enabled only if Action Mode is set to Move.
For details, refer to “Transfer
*1
” on page 8-25.
Destination Device Address: Specify the destination word device.
Click to display the Tag Editor. For the device address
configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page
2-68.
Use Reference Device Address
*1
:
Select this check box and specify a device address to change the destination word
device according
to the value of the specified device address.
This setting is enabled only if Action Mode is set to Move.
For details, refer to Chapter 2 “Indirect Read and Indirect Write Settings” on page
2-5.
Write
*1
:
Specify the number of word devices (1 to 64) at the destination.
For Move, specify how many times to write.
This setting is enabled only if Action Mode is set to Set, Move, or Set ON & OFF
Data.
For details, refer to “Write
*1
” on page 8-26.
