2 Character Input
10-32 WindO/I-NV4 User’s Manual
■ Always Entry Mode
*1
Select this check box to enter text by pressing the keypad and key buttons without touching the Character Input
displayed on the screen.
This option can only be configured if Current Screen is selected for Type.
Example: When the Always Entry mode check box is selected
Example: When the Always Entry Mode check box is cleared
*1 Advanced mode only
Enter textPress CLR Press ENT
4944
(Hex)
4543
(Hex)
‘ I ’
‘D’
4847
(Hex)
‘H’
‘G’
4847
(Hex)
‘H’
‘G’
4847
(Hex)
‘H’
‘G’
Display text being
entered (Entry mode)
Display values of
device addresses as text
(Entry mode)
Display only focus
(Entry mode)
Write character codes to
device addresses
(Entry mode)
Enter IDECDeletes text
‘E’ ‘C’
IDEC_HG_ _ IDEC_
Action
Operations
and display
Value of
Destination Device Address
Only one Numerical Input or one Character Input set to Always Entry Mode can be configured for one
screen.
Enter text
Enter IDEC
Press Character Input
Press ENT
4944
(Hex)
4543
(Hex)
‘ I ’
‘D’
Display text being
entered (Entry mode)
Display focus
(Entry mode)
Write character codes to
device addresses
(Entry mode)
4844
(Hex)
4543
(Hex)
‘ I ’
‘D’
Display values of
device addresses as text
(Display mode)
Display values of
device addresses as text
(Display mode)
4847
(Hex)
‘H’
‘G’
4847
(Hex)
‘H’
‘G’
4847
(Hex)
‘H’
‘G’
Press CLR
4847
(Hex)
‘H’
‘G’
Display only focus
(Entry mode)
Deletes text
‘C’‘E’‘E’ ‘C’
IDEC_IDEC_HG_ IDECHG
Action
Operations
and display
Value of
Destination Device Address
_
