IS810N-INT Series Servo System User Manual (Brief)Chapter 4 Wiring
4.14 General Wiring Diagram
Refer to Appendix 2 "General Wiring Diagram".
Note 1: CAT5E double shielded or better network cables are recommended. Both direct-
through and crossover Ethernet cables are allowed.
Note 2: The voltage range and maximum output current of the internal +24V power supply are
20–28 V and 200 mA.
Note 3: HDI4 and HDI8 are high-speed DIs. Use them according to their functions allocated. If
they are used in low speed circumstances, the internal ltering parameters may be increased
according to the function code.
Note 4: Customers need to prepare 5–24 V power supplies for DOs. The DO terminals support
the maximum voltage of 30 V DC voltage and maximum current of 50 mA.
Note 5: Use shielded twisted-pair cables as encoder frequency-division cables, and tie both
ends of the shield to PE. Connect GND and signal ground of the host controller reliably.
Note 6: The internal +5 V power supply supports a maximum current of 200 mA.
