Inovance IS810N-INT Series User Manual

IS810N-INT Series Servo System User Manual (Brief)Chapter 2 Product Information
- 17 -
2.1.3 Specications
1) Electrical Specications
Three-phase 380 V
Item SIZE-1 SIZE-2
Drive model IS810N T3R5 T5R4 T8R4 T012 T017 T021 T026
Continuous output current Arms 3.5 5.4 8.4 11.9 16.5 20.8 25.7
Maximum output current Arms 8.5 14 20 28 42 55 65
Main circuit power supply 537 to 679 VDC
Control circuit power supply 24 VDC, +10% to -10%
Item SIZE-2 SIZE-3
Drive model IS810N T032 T037 T045 T060 T075 T091 T112 T152
Continuous output current Arms 32 37 45 60 75 91 112 152
Maximum output current Arms 80 92.5 112.5 150 187.5 227.5 280 380
Main circuit power supply 537 to 679 VDC
Control circuit power supply 24 VDC, +10% to -10%
Note: SIZE-2 and SIZE-3 are being developed. If you have need them, contact Inovance.
