Inovance IS810N-INT Series User Manual

IS810N-INT Series Servo System User Manual (Brief) Chapter 7 Troubleshooting
- 230 -
Chapter 7 Troubleshooting
7.1 Power Supply Unit
For any faults of the power supply unit, refer to the User Guide MD810 Series AC Drive Multi-
axis System.
7.2 Drive Unit
7.2.1 Fault and Warning Grading
Faults and alarms are graded into the following three levels based on degree of severity:
NO.1 > NO.2 > NO.3.
NO.1 non-resettable fault
NO.1 resettable fault
NO.2 resettable fault
NO.3 resettable warning
"Resettable" means that the keypad stops displaying faults/warnings once the "reset signal" is
input.
To reset a fault/warning, use either of the following methods:
Set 200D-02h = 1 (fault reset enabled).
Enable the rising edge of the control word 0x6040 bit7 on the host controller.
To reset a NO.1 fault or NO.2 fault, turn off the S-ON signal and then set the DI terminal
allocated with function FunIN.2 (ALM-RST) to ON.
To reset NO.3 warning, set the DI terminal allocated with the function FunIN.2 (ALM-RST) to
ON.
Relevant objects
Index Name Data Range Description
Setting
Mode
Effective
Condition
Default
200Dh-02h
Fault
reset
0: no
operation
1: enabled
The keypad stops
displaying the
resettable faults and
warnings.
After reset, the value
is restored to 0.
Any setting Immediate
0
