IS810N-INT Series Servo System User Manual (Brief)Chapter 2 Product Information
- 33 -
2.2.3 Specications of ISMG the Servo Motor Series
1. Designation Rules and Nameplate
Note: Models ending with –A331* are standard models. Prior ordering is required for non-
standard models.
Figure 2-9 Designation rules and nameplate of the servo motor series
Mark
Base
1
2
200×200 base
266×266 base
G
Series
Mark
IS series servo
motor
ISM
×1
A
×10B
×100C
×
1000D
1 letter and 1 number
Rated Power (W)Mark
×10000E
Example: 15C: 1500 W
30D: 30000 W
ISM G1- 30D 15C D
–A
3 3 1 F A
Product Code
Mark
2
nd
generation productA
Motor ShaftMark
Plain1
Solid + keyed + tapped
hole
3
Brake, Reducer, Oil
Sealing
Mark
Oil sealing1
Customized FeatureMark
Natural coolingX
Forced coolingF
Encoder TypeMark
1 letter + 1 digit
23-bit multi-turn absolute encoderA3
Voltage ClassMark
380 VD
×1A
×10
B
×100C
×1000D
1 letter and 1 number
Rated Speed
(RPM)
Mark
×10000E
Example: 15C:1500 RPM
20C: 2000 RPM
Model
Parameters
Code
Serial
Number
Nameplat
AC Servo motor
automation
Model
ISMG1-18D20CD
Un(V)
380
In(A)
36.4
fn(Hz)
133.33
Pn(kW)
18.8
Tn(N.m)
90
n n(rpm)
2000
EFF.
92.9%
Motor Code
Type
R131FA
Duty
S4 25%Jm=9kgm
2
10
-3
Jext=36kgm
2
10
-3
IP54 3PHAC Ins.F
Weight(kg)
51.9
S/N:
IEC/EN60034-1
Manufacture: Suzhou Inovance Technology Co., Ltd./
Address: NO.16,Youxiang Road,Yuexi Town,Wuzhong District,Suzhou 215104,P.R.China
