Inovance IS810N-INT Series User Manual

IS810N-INT Series Servo System User Manual (Brief) Chapter 2 Product Information
- 48 -
2.4 Applicable Cables
2.4.1 Cables Applicable for OneCable Servo Motors (Communication Cables Included)
For specications of OneCable servo motor cables, contact Inovance.
2.4.2 Cables Applicable for ISMH Series Servo Motors (Communication Cables
Included)
Table 2-3 Cables applicable for models without a brake
Motor Model
Servo Motor Power Cable and Encoder Cable (Models Without a Brake)
Cable Type L = 3.0 m L = 5.0 m L = 10.0 m
ISMH1-*******-U1***
ISMH1-*******-U2***
ISMH4-*******-U1***
ISMH4-*******-U2***
Power cable SV82-L-M00-3.0 SV82-L-M00-5.0 SV82-L-M00-10.0
Incremental encoder
cable
S6-L-P000-3.0 S6-L-P000-5.0 S6-L-P000-10.0
ISMH1-*******-A3***
ISMH4-*******-A3***
Power cable SV82-L-M00-3.0 SV82-L-M00-5.0 SV82-L-M00-10.0
Absolute encoder
cable
S6-L-P020-3.0 S6-L-P020-5.0 S6-L-P020-10.0
ISMH2-*******-U1***
ISMH2-*******-U2***
Power cable S6-L-M11-3.0 S6-L-M11-5.0 S6-L-M11-10.0
Incremental encoder
cable
S6-L-P001-3.0 S6-L-P001-5.0 S6-L-P001-10.0
ISMH2-*******-A3***
Power cable S6-L-M11-3.0 S6-L-M11-5.0 S6-L-M11-10.0
Absolute encoder
cable
S6-L-P021-3.0 S6-L-P021-5.0 S6-L-P021-10.0
ISMH3-*******-U1***
ISMH3-*******-U2***
(1.8 kW and below)
Power cable S6-L-M11-3.0 S6-L-M11-5.0 S6-L-M11-10.0
Incremental encoder
cable
S6-L-P001-3.0 S6-L-P001-5.0 S6-L-P001-10.0
ISMH3-*******-A3***
(1.8 kW and below)
Power cable S6-L-M11-3.0 S6-L-M11-5.0 S6-L-M11-10.0
Absolute encoder
cable
S6-L-P021-3.0 S6-L-P021-5.0 S6-L-P021-10.0
ISMH3-*******-U1***
ISMH3-*******-U2***
(2.9 kW)
Power cable S6-L-M11-3.0 S6-L-M11-5.0 S6-L-M11-10.0
Incremental encoder
cable
S6-L-P001-3.0 S6-L-P001-5.0 S6-L-P001-10.0
ISMH3-*******-A3***
(2.9 kW)
Power cable S6-L-M11-3.0 S6-L-M11-5.0 S6-L-M11-10.0
Absolute encoder
cable
S6-L-P021-3.0 S6-L-P021-5.0 S6-L-P021-10.0
ISMH3-*******-U1***
ISMH3-*******-U2***
(above 2.9 kW)
Power cable S6-L-M11-3.0 S6-L-M11-5.0 S6-L-M11-10.0
Incremental encoder
cable
S6-L-P001-3.0 S6-L-P001-5.0 S6-L-P001-10.0
ISMH3-*******-A3***
(above 2.9 kW)
Power cable S6-L-M11-3.0 S6-L-M11-5.0 S6-L-M11-10.0
Absolute encoder
cable
S6-L-P021-3.0 S6-L-P021-5.0 S6-L-P021-10.0
Note: The servo motor encoder cable does not include a CN1 (DB15) connector. Please
purchase it separately. The model is S6-C6.
If you select Inovance matching cables, no connector kit is required.
