IS810N-INT Series Servo System User Manual (Brief)Chapter 2 Product Information
- 47 -
Rated
Speed
(RPM)
Max. Speed
(RPM)
Capacity
(kW)
Servo Motor Model
Motor
Frame
Drive Model Drive Size
Drive SN
(H01-10)
1500 1830 7.9 ISMG1-95C15CD-A331FA
200
IS810N50M4TD017INT
pins 2
10005
2000 2560 10.5 ISMG1-12D20CD-A331FA IS810N50M4TD021INT 10006
1500 1920
11.8 ISMG1-14D15CD-A331FA IS810N50M4TD026INT 10007
14.5 ISMG1-17D15CD-A331FA IS810N50M4TD032INT 10008
2000 2400 15.7 ISMG1-18D20CD-A331FA IS810N50M4TD032INT 10008
1500 1830 18.1 ISMG1-22D15CD-A331FA IS810N50M4TD037INT 10009
2000 2560
19.3 ISMG1-23D20CD-A331FA IS810N50M4TD037INT 10009
24.1 ISMG1-28D20CD-A331FA
IS810N50M4TS045INT 10010
1500 1920 23.6 ISMG1-30D15CD-A331FA
2000 2400 31.4 ISMG1-41D20CD-A331FA IS810N50M4TS060INT 10011
1500 1830 26.7 ISMG2-31D15CD-A331FA IS810N50M4TS060INT 10011
2000 2560 35.6 ISMG2-42D20CD-A331FA
266
IS810N50M4TS075INT 10012
1500 1920
36.1 ISMG2-42D15CD-A331FA
44.8 ISMG2-52D15CD-A331FA IS810N50M4TS091INT
3
10013
2000 2400 48.2 ISMG2-57D20CD-A331FA IS810N50M4TS091INT 10013
1500 1830 53.4 ISMG2-60D15CD-A331FA IS810N50M4TS112INT
2000 2560
59.7 ISMG2-70D20CD-A331FA IS810N50M4TS112INT 10014
71.2 ISMG2-80D20CD-A331FA
IS810N50M4TS152INT 10015
1500 1920
69.1 ISMG2-80D15CD-A331FA
80.1 ISMG2-94D15CD-A331FA
2000 2400 92.1 ISMG2-11E20CD-A331FA IS810N50M4TS152INT 10015
