IS810N-INT Series Servo System User Manual (Brief)Chapter 2 Product Information
- 15 -
Chapter 2 Product Information
An MD810 power supply unit must be purchased before the use of this product. For information
about the specifications of the power supply unit, refer to the User Guide MD810 Series AC
Drive Multi-axis System.
2.1 Drive Unit
2.1.1 Designation Rules and Nameplate
Figure 2-1 Designation rules and nameplate of drive unit
MODEL： IS810N50M4TD012INT
INPUT： DC 537V-679V
OUTPUT1：3PH AC 0-380V 11.9A 0-400Hz
S/N： 010501934H700001
Suzhou Inovance Technology Co., Ltd.
Drive model
Rated input
Rated output
Serial No.
Nameplate
Certificates
OUTPUT2：3PH AC 0-380V 11.9A 0-400Hz
010380134FB00363 IS810N50M4TD012INT
