IS810N-INT Series Servo System User Manual (Brief)Chapter 3 Installation
- 63 -
3.2.2 Removal and Installation of a Power Supply Unit Cover
Cover Removal
Lift the translucent keypad
cover. Loosen the screws
in the upper cover with a
screwdriver.
Remove the upper cover by
rotating it forward.
Pull the whole keypad box
forward.
Hold the bottom of the lower
cover with your hands.
Remove the lower cover by
rotating it forward.
Insert a tool (screwdriver) into
the clip of the power terminal
cover. Pry the clip.
Remove the power terminal
cover.
