IS810N-INT Series Servo System User Manual (Brief) Chapter 3 Installation
- 62 -
Two-row installation
Book-type unit Vertical unit
Thermal
insulation
deflector
Thermal
insulation
deflector
Thermal
insulation
deflector
Thermal
insulation
deflector
Note:
An insulation deector may be installed on the upper unit layer in two-row
installation.
Do not merely install two or less servo drives.
The through-hole mounting method supports only single-row installation.
