IS810N-INT Series Servo System User Manual (Brief)Chapter 3 Installation
- 57 -
Model
MD810-20M4T***G***(W)
Dimensions Voltage class
45
[H]: 350 mm
[H1]: 384 mm
[H2]: 400 mm
[W]: 100 mm
[W1]: 50 mm
[D]: 305 mm
380-480 VAC
110
[H]: 350 mm
[H1]: 384 mm
[H2]: 400 mm
[W]: 200 mm
[W1]: 150 mm
[D]: 305 mm
160 (Air cooled)
[H]: 350 mm
[H1]: 384 mm
[H2]: 400 mm
[W]: 300 mm
[W1]: 250 mm
[W2]: 150 mm
[D]: 305 mm
160 (Water cooled)
[H]: 350 mm
[H1]: 384 mm
[H2]: 415.5 mm
[W]: 300 mm
[W1]: 250 mm
[W2]: 150 mm
[D]: 305 mm
355
[H]: 800 mm
[H1]: 795 mm
[H2]: 832 mm
[W]: 180 mm
[W1]: 105 mm
[D]: 445 mm
