LABEL LOCATIONS

Part No 1125104 11 ProSPIN™ X4™

LABEL LOCATIONS

Standard Labels

Refer to Owner's Manual

for proper anti-tipper

setting.

1085379

WARNING

Quick Release Axles ONLY

Serial Number

Label Location

Standard Frame ONLY

Heavy Duty Frame ONLY

WARNING

DO NOT OPERATE WITHOUT

THE ANTI-TIP TUBES

INSTALLED.

REV. 5/98

P/N 60106X144

or
