Invacare ProSPIN X4 - Suspension Forks

SECTION 12—CASTERS, FORK AND FORK STEM ASSEMBLIES
ProSPIN™ X4™ 80 Part No 1125104
Suspension Forks
NOTE:Forthisprocedure,refertoFIGURE12.2.
Removing the Caster
NOTE:Onemountingscrewwillnotturn.
1. Usingtwoallenwrenches,turnmountingscrewsinoppositedirectionsandremove
onemountingscrewfromfork.
2. Removethethreadedbushingwithmountingscrew andtwospacerssecuringthe
castertothefork.DONOTuseexcessiveforce.
3. Removethecasterfromthefork.
Installing the Caster
1. Alignthecasterwiththedesiredmountingholesinthefork.
2. Insertthethreadedbushingwithmountingscrew,throughthetwoaxlespacersand
caster.DONOTuseexcessiveforce.
 WARNING
Use Loctite™242 when reinstalling the mounting screw into the threaded bushing.
Otherwise the fork can become disassembled. Possible injury or damage could
result.
3. ApplyLoctite242tothemountingscrew.
4. Reinstallthemountingscrewintothethreadedbushingandtightensecurely.
FIGURE 12.2 Removing/Installing/Repositioning the Caster Assemblies - Suspension Forks
Fork
Mounting
Screw
Axle
Spacer
Threaded Bushing
Caster
Mounting
Screw
Axle
Spacer
