SECTION 8—ARMS
ProSPIN™ X4™ 52 Part No 1125104
Adjusting T-Arm Sockets
NOTE:Forthisprocedure,referto
FIGURE8.7.
NOTE:PerformthisprocedureiftheT‐armis
toolooseinthesocketordoesnoteasilyslideup
anddowninthesocket.
1. Removetherearwheelsfromthe
wheelchair,ifnecessary.Referto
Removing/InstallingRearWheelson
page 67.
2. Loosen,butDONOTremovethefour
hexscrewsandwashersthatsecureT‐
armsockettoT‐armclamp.
NOTE:TheT‐armsocketwilldisassembleif
thefourhexscrewsandwashersareremoved.
FIGURE 8.7 Adjusting T-Arm Sockets
3. SlidetheT‐armintotheT‐armsocketuntilthelockingleverisintheslotintheT‐arm
socketandanaudibleʺclickʺisheard.
4. SqueezetheT‐armsocketandtheT‐armclamptogetheruntilthesocketisflushwith
theT‐arm.
5. WhileholdingtheT‐armsocketandtheT‐armclamptogether,tightenthefourhex
screwsandwashers.Tightensecurely.
6. PressinonthelockingleverandlifttheT‐armstraightupandoutoftheT‐armsocket.
7. RepeatSTEPS3‐6,ifnecessaryuntiltheT‐armslidesintheT‐armsocketasdesired.
8. Ifnecessary,installrearwheels.RefertoRemoving/InstallingRearWheelsonpage 67.
Hex Screws
and Washers
T-Arm
Hex Screws
and Washers
T-Arm Socket
T-Arm Clamp
Locking Lever
Slot
