Invacare ProSPIN X4 - Adjusting T-Arm Transfer Assists and;or Side Guards

SECTION 8—ARMS
Part No 1125104 53 ProSPIN™ X4™
Adjusting T-Arm Transfer Assists and/or Side Guards
NOTE:Forthisprocedure,refertoFIGURE8.8.
1. RemovetheT‐armfromthewheelchair.RefertoInstalling/RemovingT‐Armson
page 49.
2. Removethetwomountingscrewsthatsecurethesideguardtothebottomclamp.
NOTE:Adjustingthesideguardswilldirectlyaffectthepositionofthetransferassist.
3. Performoneofthefollowing:
•SmallSideGuards‐Movethebottomclampuptooneoftwomountingpositions
inthesideguard.
• LargeSideGuards‐Movethebottomclampuptooneofthreemountingpositions
inthesideguard.
4. Securethesideguardtothebottomclampwiththetwomountingscrews.
5. InstalltheT‐armontothewheelchair.RefertoInstalling/RemovingT‐Armson
page 49.
FIGURE 8.8 Adjusting T-Arm Transfer Assists and/or Side Guards
Mounting Screws
Bottom Clamp
Transfer Assist
Side Guard
T-Arm
