SECTION 14—SEAT-TO-FLOOR HEIGHT
ProSPIN™ X4™ 92 Part No 1125104
Measuring Seat-to-Floor Height
NOTE:Forthisprocedure,refertoFIGURE14.2.
NOTE:Allmeasurementsareininches.Thefrontandrearseat‐to‐floorheightsareapproximate
to±¼‐inchduetotirewearandairpressure.
Measuring Front Seat-to-Floor Height
FrontSeat‐to‐FloorHeight:Measurethedistancebetweenthefrontoftheseatupholstery
andtheground/floor.
Measuring Rear Seat-to-Floor Height
NOTE:Therearseat‐to‐floorheightsarebasedonpneumatictiresandpneumatictireswithflat
freeinserts.Ifwheelchairisequippedwithurethanetires,subtract1/4‐inchfromthemeasurement.
RearSeat‐to‐FloorHeight:Measuredistancebetweentherearoftheseatupholsteryand
theground/floor.
FIGURE 14.2 Seat Dump
Changing Seat-to-Floor Height
 WARNING
The seat height, seat depth, back angle, seating system, size/position of the rear
wheels, size/position of the front casters, as well as the user condition directly relate
to the stability of the wheelchair. Any change to one or any combination of the nine
may cause the wheelchair to decrease in stability. These adjustments MUST be per-
formed by a qualified technician.
Front
Seat-to-Floor Height
Rear
Seat-to-Floor Height
Seat Upholstery
