SECTION 7—FRONT RIGGINGS
Part No 1125104 41 ProSPIN™ X4™
Installing Adjustable Angle Flip-up Footplate Hinge
NOTE:Forthisprocedure,refertoFIGURE7.2.
NOTE:Thisprocedureisforindividualadjustableanglefootrestsonly.
1. Positiontheadjustableangleflip‐upfootplatehingeonthefootrestsupporttubeatthe
desiredheight.
2. Usingthemountingscrewandlocknut,looselysecuretheadjustableangleflip‐up
footplatehingetothefootrestsupporttube.
3. Flipthefootplatehingetotheupposition.
NOTE:Thefootplatehingewillfalltothedownposition.
4. Tightenthemountingscrewandlocknutthatsecurethefootplatehingetothefootrest
supportuntilthefootplatehingeremainsintheupposition.
5. Checktheupanddownmotionofthefootplatehingetomakesuretheuserofthe
wheelchaircanoperatethefootplateseasily.
NOTE:Ifthefootplateʹsmotionistootight,loosenthesocketscrewandlocknutapproximately¼ ‐
turn.
FIGURE 7.2 Installing Adjustable Angle Flip-up Footplate Hinge
Footplate
Hinge
Locknut
Footrest
Support
Tube
Mounting
Screw
