Invacare ProSPIN X4 - Converting from Pull-To-Lock to Push-To-Lock

SECTION 6—WHEEL LOCKS
Part No 1125104 39 ProSPIN™ X4™
NOTE:Asthewheellockhandleispusheddownwards,thewheellockwillengageandthen
disengagethewheel.
2. Pushwheellockhandledowntoaccesstheupperstopposition(Detail“B”).
3. Installsetscrewintoupperstopposition.
4. Pullwheellockhandleuptoengagewheellock.Ifwheellockdoesnotproperly
engagethewheel,refertoAdjustingtheWheelLockonpage 37.
Converting From Pull-to-Lock to Push-to-Lock
1. Removesetscrewfromtheupperstopposition(Detail“B”).
NOTE:Asthewheellockhandleispulledupwards,thewheellockwillengage andthendisengage
thewheel.
2. Pullwheellockhandleuptoaccessthelowerstopposition(Detail“A”).
3. Installsetscrewintolowerstopposition.
4. Pushwheellockhandledowntoengagewheellock.Ifwheellockdoesnotproperly
engagethewheel,refertoAdjustingtheWheelLockonpage 37.
FIGURE 6.3 Converting Wheel Lock From Push-to-Lock to Pull-to-Lock or Pull-to-Lock to
Push-to-Lock
DETAIL “A” WHEEL LOCK IN
PUSH-TO-LOCK CONFIGURATION
Set Screw
(in Lower Stop Position)
Wheel Lock Handle
DETAIL “B” WHEEL LOCK IN
PULL-TO-LOCK CONFIGURATION
Set Screw
(in Upper Stop Position)
Wheel Lock Handle
