SECTION 4—WHEELCHAIR OPERATION
Part No 1125104 31 ProSPIN™ X4™
Using Conventional Adjustable Height Armrests
 WARNING
DO NOT operate or replace flip-back armrest when wheelchair is folded -
otherwise injury or damage may result.
Ensure armrest is securely locked into arm socket and armrest release button locks
into place before using.
NOTE:Forthisprocedure,refertoFIGURE4.7.
NOTE:Formaintenanceand/oradjustmentprocedures,refertoArmsonpage 47.
1. Pushdownonfrontofarmresttoensureitisfullyseatedinfrontsocket.
NOTE:Thisstepisneededtopreventthereleasebuttonfromhanginguponthefrontarmsocket.
2. Pullthearmrestreleaseleverlocatedonarmrestfronttubetodisengagetherelease
buttonfromthefrontarmsocket.
3. Rotatefrontofarmrestupandoutoffrontarmsocket.
NOTE:Armrestcanrotatebackapproximately90°.
4. Topreparearmrestforuse,rotate armrestdownward,makingsurefronttubeof
armrestinsertsintoarmsocket.
5. Pusharmrestdownuntilreleasebuttonsnapsintofrontarmsocket.
6. Ensurearmrestissecurelylockedintofrontarmsocketandreleasebuttonlocksinto
placebeforeusing.
FIGURE 4.7 Using Conventional Adjustable Height Armrests
Conventional
Adjustable Height
Armrest
Armrest Release Lever
Front Arm Socket
Armrest Front Tube
Release Button
