Invacare ProSPIN X4 - Installing;Removing Elevating Legrests; Installing; Removing; Raising;Lowering the Elevating Legrest

SECTION 4—WHEELCHAIR OPERATION
ProSPIN™ X4™ 30 Part No 1125104
Installing/Removing Elevating Legrests
NOTE:Forthisprocedure,refertoFIGURE4.5.
Installing
1. Placeelevatinglegrestontheoutsideofthewheelchairandinsertmountingpininto
themountingtube.
2. Rotateelevatinglegresttowardtheinsideofthewheelchairuntilitlocksinplace.
NOTE:Thecalfpadofthelegrestwillbeonthe
insideofthewheelchairwhenlockedinplace.
3. RepeatSTEPS1‐3fortheother
elevatinglegrestassembly.
Removing
1. Pushthelegrestreleasehandleinward
whilerotatingtheelevatinglegrest
outward.
2. Liftthelegrestassemblyoutofthe
mountingtubeofthewheelchairframe.
3. RepeatSTEPS1‐2foroppositeside,if
necessary.
FIGURE 4.5 Installing/Removing Elevating
Legrests
Raising/Lowering the Elevating Legrest
NOTE:Forthisprocedure,referto
FIGURE4.6.
1. Performoneofthefollowing:
• Raising:Liftlegrestassemblyupto
desiredheight.
•Lowering:Liftelevatinglegrest
assemblyupwithonehand.While
supportingtheelevatinglegrest
assembly(anduser’sleg),pull
releaseleverupwithotherhand
andlowerlegrestassemblyto
desiredheight.
FIGURE 4.6 Raising/Lowering the Elevating
Legrest
Release
Handle
NOTE:Themountingtubewillbepartof
theseatframeorwheelchairfrontframe
dependingonwheelchairmodel.
Mounting Pin
Mounting
Tube
Elevating
Legrest
Inside of
Wheelchair
Release Lever
Elevating Legrest
Assembly
