SECTION 7—FRONT RIGGINGS
Part No 1125104 45 ProSPIN™ X4™
Adjusting Elevating Legrest Height and Calfpad
Height/Depth
NOTE:Forthisprocedure,refertoFIGURE7.7.
Adjusting the Footplate Height
1. Loosenlocknutandwashersecuringtheslidetubetotheelevatinglegrest.
2. Repositionfootplatetodesiredheightsecurelytightenlocknutandwasher .
3. Ifnecessary,repeatSTEPS1‐2toadjustremainingfootplateheight.
Adjusting Calfpad Height
1. Loosenthemountingboltandwasherthatsecurethecalfpadbrackettotheelevating
legrestassembly.
2. Slidethecalfpadbracketupordownuntilthedesiredcalfpadheightisobtained.
3. Tightenthemountingboltandwashersecuringthecalfpadbrackettotheelevating
legrestassembly.
4. Ifnecessary,repeatSTEPS1‐3toadjustremainingcalfpadbracket.
Adjusting Calfpad Depth
1. Removethemountingscrew,spacerandlocknutthatsecurethecalfpadtothecalfpad
bracket.
2. Insertmountingscrewthroughoneoffourcalfpadbracketmountingholes.
3. Usingthemountingscrewspacerandlocknut,securethecalfpadtothecalfpadbracket.
4. Ifnecessary,repeatSTEPS1‐3toadjustremainingcalfpadassembly.
FIGURE 7.7 Adjusting Elevating Legrest Height and Calfpad Height/Depth
Calfpad Bracket Mounting Holes
Calfpad Bracket
Mounting Screw
Locknut
Calfpad
Mounting Bolt and Washer
Spacer
Slide Tube
Footplate
Elevating Legrest Assembly
Locknut and Washer
