Invacare ProSPIN X4 - Adjusting Armrest Height; Replacing Conventional Adjustable Height Armrest Arm Pad

SECTION 8—ARMS
ProSPIN™ X4™ 48 Part No 1125104
Adjusting Armrest Height
1. Lifttheheightadjustmentleveruptotheunlocked(vertical)position.
2. Adjustarmresttodesiredheight.
3. Presstheheightadjustmentleverdowntothelocked(horizontal)position.
FIGURE 8.1 Removing/Installing/Adjusting Conventional Adjustable Height Armrests
Replacing Conventional Adjustable Height Armrest
Arm Pad
NOTE:Forthisprocedure,refertoFIGURE8.2.
1. Removethemountingscrewsthatsecurethearmpadtothearmrestassembly.
2. Replacearmpadandsecurelytightenwiththeexistingmountingscrews.
3. RepeatSTEPS1‐2fortheoppositesideifnecessary.
FIGURE 8.2 Replacing Conventional Adjustable Height Armrest Arm Pad
Locked
(Horizontal)
Unlocked
(Vertical)
Rear Armrest
Release Lever
Height Adjustment
Lever
Front Armrest
Release Lever
Armrest Socket
Armrest Socket
Arm Pad
Armrest
Assembly
Mounting Screw
Mounting
Screw
